The TL-SG1024DE 24-Port Gigabit Easy Smart switch is an ideal upgrade from an unmanaged switch, designed for Small and Medium Business networks that require simple network management. Network administrators can effectively monitor traffic viaPort Mirroring, Loop Prevention and Cable Diagnostics features. To optimize traffic on your business network, TL-SG1024DE offers Port-based/802.1p/DSCP QoS1 to keep latency-sensitive traffic moving smoothly and jitter-free. Additionally, port-based, tag-based and MTU VLAN can improve security and meet more network segmentation requirements. Moreover, with its innovative energy-efficient technology, the TL-SG1024DE can save up to 18% of power consumption, making it an eco-friendly solution for your business network.
(TL-SG1024DE)
-
24 10/100/1000Mbps ports provide instant large file transfers
-
Innovative energy-efficient technology reduces power consumption by up to 18%
-
IEEE 802.3x flow control provides reliable data transfers
-
9K Jumbo frame improves performance of large data transfers
-
Effective network monitoring via Port Mirroring, Loop Prevention and Cable Diagnostics
-
Port-based/802.1p/DSCP QoS1 enable smooth latency-sensitive traffic
-
Abundant VLAN features improve network security via traffic segmentation
-
IGMP Snooping optimizes multicast applications
-
Web-based user interface and management utility simplify configuration
HARDWARE FEATURES
|
Standards and Protocols
|
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p
|
Interface
|
24 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX
|
Network Media
|
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100O STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100O STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100O STP (maximum 100m)
|
Fan Quantity
|
Fanless
|
Power Supply
|
100-240VAC, 50/60Hz
|
Power Consumption
|
Maximum: 14.86W (220V/50Hz)
|
Dimensions ( W x D x H )
|
11.6*7.1*1.7 in. (294*180*44 mm)
|
PERFORMANCE
|
Switching Capacity
|
48Gbps
|
Packet Forwarding Rate
|
35.7Mpps
|
MAC Address Table
|
8K
|
Packet Buffer Memory
|
512KB
|
Jumbo Frame
|
9KB
|
SOFTWARE FEATURES
|
Quality of Service
|
Support Port-based/802.1p/DSCP priority
Support 4 priority queues
Rate Limit
Storm Control
|
L2 Features
|
IGMP Snooping V1/V2/V3
Link Aggregation
Port Mirroring
Cable Diagnostics
Loop Prevention
|
VLAN
|
Supports up to 128 VLANs simultaneously (out of 4K VLAN IDs)
MTU/Port/Tag VLAN
|
Transmission Method
|
Store-And-Forward
|
OTHERS
|
Certification
|
FCC, CE, RoHS
|
Package Contents
|
TL-SG1024DE, Power Cord, Installation Guide, Resource CD, Rackmount Kit, Rubber Feet
|
System Requirements
|
Microsoft® Windows® for running Utility
|
Environment
|
Operating Temperature: 0?~40? (32?~104?)
Storage Temperature: -40?~70? (-40?~158?)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
|
SKU |
TL-SG1024DE |
Model # |
TL-SG1024DE |
Barcode # |
6935364021245 |
Brand |
TP-Link |
Shipping Weight |
1.9700kg |
Shipping Width |
0.290m |
Shipping Height |
0.040m |
Shipping Length |
0.180m |
Unit Of Measure |
ea |
Type |
store |
3 Years Limited Manufacturer Warranty
